Skyrobot FX-450 Fixed-Wing long endurance tactical UAS

About

SkyRobot - SkyRobot™ FX450 is a fully autonomous UAV system developed to provide balance between advanced capabilities and operation in challenging environments.

The system is based on a high-performance UAV that can be fitted with a wide variety of custom payloads. Capable to cover 2.500km range while carrying a multi-axis stabilized payload with a range of different sensors.

SkyRobot™ FX450 is engineered to provide 20h+ persistent support for long enduring security & surveillance needs while being safe to use and providing highest level of mobility at competitive costs.

Use cases

  • Land & maritime missions

  • Long range ISR and target acquisition

  • IED/Threat detection/Change Detection

  • Maritime traffic monitoring

  • Pollution monitoring

Description

Range (LOS) ➜

Range (SAT-COM) ➜

Mission Radius ➜

Service Ceiling ➜

Cruise Speed ➜

Fuel ➜

Propulsion ➜

Transponder ➜

Avionics ➜

Length ➜

Height ➜

Wingspan ➜

MTOW ➜

Empty Weight ➜

Payload ➜

Nav-system ➜

Endurance ➜

Mission ➜

Two man crew

Nato stanag 4586

Modular design

ATOL

Environmental capability

Spec

200 km

2.500 km (optional)

2.500 km

5.000 m

125 km/h

Gasoline

Hp two-stroke, fuel-injection

Mode C & Mode S

IMU, GPS, redundant systems

4,10 m

1,2 m

7,2 m

200 kg

100 kg

30 kg

GPS, Beidou, GNSS

20 h+

Blos

SkyRobotTM FX450, reliability in any mission

Two man crew

The ground control station contains from two computers, communications link and monitors. One operator is the pilot in command and is responsible for aircraft operation and monitoring of aircraft system health. The second operator is the sensor operator. This person is responsible for sensor control and monitoring of communication link integrity.

Safety

From a triple redundant autopilot to double redundant datalink, SkyRobotTM FX450 is packed with safety measures that increase robustness and reliability for all weather operations

Its carbon-fiber and fiberglass airframe structure offer the structural integrity expected in manned aircraft standards. SkyRobotTM FX450 has been proven in many different harsh environments, including hot conditions at high ambient temperatures and relative humidity, as well as cold, snowy conditions. The air vehicle is capable of take-off, flight operations, and recovery in temperatures ranges well below freezing and up to +55°C degrees.

Energy efficient

SkyRobotTM FX450 has very low energy consumption and greenhouse gas emissions compared to manned aircraft with the same payload capability. System can be airborne for 20+ hours, covering 5,500km2 per flight, and only consuming 100 liters of gasoline.

SkyRobotTM FX10 is hand launched and slide on fuselage or net recovered UAS

Payload

  • 40x zoom (20x optical, 2x digital)

    Resolution: 1280x720 pixels, 720P HD

  • Resolution: 640 x 480 pixels, 480P SD

    Spectral band: 8 – 12 μm (LWIR)

    Frame Rate: 30 Hz (NTSC) or 25 Hz (PAL)

Ground Control Station

  • Mini rugged GCS allows user to plan missions, direct the flight of the aircraft, control the gimbal, and land the UAV in fully autonomous, semi-autonomous and manual modes. This GCS features 10,1” multi touch screen, 4 hours battery life, 128GB SSD internal storage, HID joysticks for manual control, IP65 environmental protection, WiFi, LTE, Bluetooth and weighs only 1,2kg.

Get in contact with us to know more about the SkyRobotTM FX450
